CAT Receiver/ VideoScaler (HDBaseT) HDMI / LAN/ RS232/ IR/ PoE 100m PU-507RX-SCD
PU507RXSCD
This advanced device is capable of transmitting pure digital HDMI (max. 1080p) with Audio or DVI signal. The system transmitting also LAN, IR and RS232 tw signals and PoE with 1UTP CAT5 (up to 80m) or CAT6/7 (up to 100m) cable with HDBaseT technology 5Play.The internal VideoScaler support resolution up to 1920x1200.
Legen Sie dieses produkte in den Beraterkorb und fordern Sie anschlieÃend eine kostenlose Beratung an!
Description
Technical Specification
Inputs:
1 x RJ45 (HDBaseT) female
1 x 3,5mm jack IR female
Outputs:
1 x HDMI female
1 x Toslink female
1 x 3,5mm jack female
1 x D-Sub 9-Pin RS232 female
1 x 3,5mm jack IR female
1 x RJ45 female LAN
Resolutions supported:
VGA, SVGA, XGA, WXGA, SXGA, UXGA, WUXGA and 480i to 1080p
Formats supported:
Video: HDMI1.3 (10,2 Gbps), HDCP 1.1 and DVI 1.0 (Deep Color 10 & 12 bit), CEC
Audio: Audio7.1, Dolby TrueHD
