CAT Transmitter/ Verteiler 1:4 (HDMI/AVLC) HDMI 4K/RS232/ IR/ PUV-1H4HPL-AVLC
PUV1H4HPLAVLC
he PUV-1H4H-AVLC is a single HDMI Input to 4 x HDBaseT™ Output Distribution Amplifier (Splitter). An advanced solution for splitting and distributing a single HDMI input (up to 4K@60Hz, HDMI 2.0 & HDCP 2.2) to 4 HDBaseT outputs as well as a single local HDMI output with analogue stereo audio de-embedding.
Legen Sie dieses produkte in den Beraterkorb und fordern Sie anschlieÃend eine kostenlose Beratung an!
Description
Technical Specification
Inputs:
1 x HDMI fe
1 x 3,5 mm Sub-D Pin for RS232
2 x 3,5 mm Jack for IR
1 x Mini USB for Service
Outputs:
1 x HDMI fe
1 x Phoenix Terminal Block f. Audio
1 x 3,5 mm Jack for IR out
Controll options:
CEC, RS232, Mini-USB and IR
supported Resolutions:
640x480 bis 3840x2160@60Hz
Formates:
Video: HDMI1.4, HDCP 1.1 und DVI 1.0 (Deep Color 10 & 12 bit) max. 10.2 Gbps per Chanel
Audio: 8 Kanäle digital, Analog 2 Kanäle
