CAT TX (HDBT3) USB-C UHD,4K/ LAN/ PoH/ HDMI OUT 100m PUV-C3050TX
PUVC3050TXUA
Transmission HDMI/ HDCP2.2 (max. UHD/ 4K/ 1080p@60Hz), Audio, LAN, IR and RS232 tw signals with 1 CAT6a/ CAT7 (up to 100m) cable. The system support the 5 Play technology. Full HDCP compatible. PoH (Power over HDBaseT) for Receiver PUV-1510RX.
Legen Sie dieses produkte in den Beraterkorb und fordern Sie anschlieÃend eine kostenlose Beratung an!
Description
Technical Specification
Inputs:
1 x USB-C female
2 x USB2.0 A female
1 x Phoenix 3 Pin female (Analog Audio)
1 x Phoenix 4 Pin female (RS232)
1 x Phoenix 4 Pin female (IR)
1 x RJ45 Buchse (LAN)
Outputs:
1 x RJ45 female (HDBaseT3)
1 x HDMI female
1 x Phoenix 3 Pin female (Analog Audio)
Resolutions supported:
VGA to WUXGA, 2560x1440, 2560x1600 and 720p to 1080p and UHD/4K@60Hz 4:4:4
Formats supported:
Video: HDMI2.0, HDCP2.2/ 1.4, CEC und DVI 1.0
Audio: Stereo Audio
Control: USB1.1, USB2.0 (max. 300 Mbps)
Standard: HDBaseT3
