Controllable amplifier 2 x 30W/ switcher HDMI 2x1 AU-A300
AUA300
Audio amplifier 2 channel with 2 HDMI, 2 analoge, 2 digital and 1 Microphon inputs. The amplifier switch the inputs to 1 HDMI, 2 digital, 1 analog and the Speaker Terminals. Supports Digital to Analogue (DAC) and Analogue to Digital (ADC) conversion.
Legen Sie dieses produkte in den Beraterkorb und fordern Sie anschlieÃend eine kostenlose Beratung an!
Description
Technical Specification
Inputs:
2 x HDMI female
1 x 3,5mm mini jack female
1 x 2 RCA female Stereo
1 x RCA female (SPDIF)
1 x Toslink female
Outputs:
2 x HDMI female
1 x 3,5mm mini jack female
1 x 2 RCA female Chinch Stereo
1 x RCA female (SPDIF)
1 x Toslink female
4 x Speaker Binding Posts
Control options:
Frontpanel, Ethernet, RS232, IR
Resolutions supported:
640x480 to 1920x1200 or 480i to 1080p
Formats supported:
Video: HDMI 1.3, HDCP 1.1 und DVI 1.0
Audio: digitale and analoge Audio (DAC / ADC),
Power: 2 x 30 Watt
