Converter SD-/ HD-/ 3G/ 6G/ 12G-SDI to HDMI2.0 UHD/ 4K PRO-SDI2H
PROSDI2H
The PRO-SDI2H, SDI to HDMI Converter, allows SD, HD, 3G and 12G-SDI signals to be shown on HDMI display. This means that it is now easier for professionals to distribute and extend their SDI signal while giving the ability to display work on HDMI displays. Furthermore, thanks to L/R audio outputs users can output audio in analog formats while the loop-through 12G-SDI design benefits users by letting them simultaneously show content on both SDI and HDMI displays.
Legen Sie dieses produkte in den Beraterkorb und fordern Sie anschlieÃend eine kostenlose Beratung an!
Description
Technical Specification
Input:
1 x BNC female
Outputs:
1 x BNC female
2 x HDMI female
1 x 3,5mm mini Jack female
Resolutions supported:
480i, 576i, 720p 50/60 Hz, 1080i 50/60 Hz, 1080p 50/60 Hz & UHD/ 4K@60Hz 8 bit (YUV 4:2:2)
Formats supported:
Video: HDMI2.0, HDCP, DVI und SD-SDI bis 12G-SDI
Audio: digitales (embedded Audio bis 8 Kanäle PCM 48 KHz für HDMI), 2 Kanal analoges Audio
