Matrix Switcher SD-SDI/ HD-SDI/ 3G-SDI 4x4 PRO-SDI44
PROSDI44
Allows the connection of 4 SD-SDI/ HD-SDI/ 3G-SDI sources to 4 display devices. With a local control panel. Supports all SD-SDI to 3G-SDI formats from 270 Mbps to 2,970 Gbps. Autom. cable equalization for max. 100 m cable length input side @ 2,970 Gbps.
Preis auf Anfrage
Legen Sie dieses produkte in den Beraterkorb und fordern Sie anschlieÃend eine kostenlose Beratung an!
Description
Technical Specification
Inputs:
4 x BNC female
Outputs:
4 x BNC female
Control options:
Frontpanel, RS232 or IR
Resolutions supported:
480i to 1080p
Formats supported:
Video: 2.970 Gbps, 2.970/1.001 Gbps, 1.485 Gbps, 1.485/1.001 Gbps und 270 Mbps / SMPTE 425M (Level A and Level B), SMPTE 424M, SMPTE 292M, SMPTE 259M-C
Producer
CYP Europe
Product
PROSDI44
Gehäuse
Metall
Weight (kg)
2,40
Color
Schwarz
Power supply type
Extern
Stromversorgung
5 V/ 2,6 A DC
Abmessungen BxHxT mm
436 x 93 x 132
Artikel Nr.
6237
