Media Player, LAN, 2 USB, RS232, 8 GPIO, HDMI IN XD1230
XD1230
Capable of playing Videos (up to: 2 x 1080p or 4 x 720p/1080i), Images and Audio files in multiple zones or as looping playlists. Content may be added or changed over the network using BrightAuthor or Easescreen (coming soon) software. Event sequences can be triggered by GPIO, Ethernet (UDP), RS232, USB and USB Touch Screens. Synchronization of multiple Players over the network. Additional features are: Playlist scheduling, Online Reports, Text ticker, RSS Feed and Twitter Feeds. Event Logging and displaying of World Time including Date are supported as well.
Legen Sie dieses produkte in den Beraterkorb und fordern Sie anschlieÃend eine kostenlose Beratung an!
Description
Technical Specification
Input:
1 x SDXC slot (up to 2TB)
1 x HDMI female
1 x RF female ATSC/Clear QAM Tuner only for US market
Outputs:
1 x HDMI female
1 x VGA female (VGA, Component, S-Video, Component via VGA)
1 x Toslink optical Audio female
1 x 3,5mm mini Jack Audio female
1 x 3,5mm mini Jack IR female
Control options:
LAN, 2 USB, RS232, 8 GPIO (bi-directional), CEC
Resolutions supported:
HDMI: 4K, 1080p, 1080i, 720p, 576p, 480p, 1024x768, 800x600
VGA: 1280x800, 1280x768, 1360x768, 1024x768, 640x480
Video: PAL/ NTSC
Formats supported:
Video: MPEG-1, MPEG-2 , MPEG-2 TS und Programm Streams, H.264, WMV, AVCHD/BDAV, ASF, MP4, MOV, 3D (MVC, side-by-side, top-over-bottom, frame-packing)
Bild: HTML5, BMP, JPEG and PNG
Audio: MP2, MP3, AAC, WAV (AC3 pass trough)
