Mediaplayer 3840x2160@60Hz, LAN, 3 USB, RS232, 8 GPIO, PoE+ XD1035

Hersteller

XD1035

Full screen or multi screen layouts, 4K video with HDR10 and HLG, looping playlists, webside HTML5 (Enterprise), Update content via LAN, interactiv solutions with GPIOs, RS232, touch screen , USB possible, synchronisation of several media players, online reports, text ticker or RSS feeds, world clock with date.

€ 890,00 Excl. VAT .

Legen Sie dieses produkte in den Beraterkorb und fordern Sie anschließend eine kostenlose Beratung an!

Description


Technical Specification

Input:
1 x Micro SDXC slot (up to 2TB)
Outputs:
1 x HDMI female
1 x 3,5mm mini Jack Audio female (analog & digital)
Control options:
LAN Gbit (PoE+), WLAN optional, CEC, 2 USB A & C, RS232, 8 GPIO bi-directional, IR (In/ Out)
Resolutions supported: (UHD)
3840x2160x24/ 25/ 30/ 50/ 60Hz
Resolutions supported: (Upscaling)
3840x2160x24/ 25/ 29.97/ 30Hz
Resolutions supported: (Full HD)
1920x1080@24/ 25/ 29.92 /30 /50 /59.94 /60Hz,
1920x1080x50/ 59.94 /60i, 1600x1200x60Hz, 1440x1050x60/ 75Hz, 1440x900x60/ 75Hz, 1360x768x60Hz, 1280x1024x60/ 75Hz, 1280x960x60Hz, 1280x800x60 /75Hz, 1280x768x60Hz,
1280x720x50/ 59.94/ 60Hz, 1024x768x60Hz, 800x600x60/ 75Hz, 720x576x50Hz/50i, 720x480x59.94/ 60Hz/60i, 640x480x60Hz
Formats supported:
Video: H.265 (4K) .ts, .mov, .mp4, .mkv & H.264 (1920x1080)(MPEG-4, Part 10), MPEG-2 und MPEG-1
Video codec: .ts, .mpg, .vob, .mov, .mp4, .m2ts
Bild: BMP, JPEG and PNG
Audio: MP2, MP3, AAC, WAV (AC3 5.1 Audio pass trough)
HTML5: Enterprise

Producer
BrightSign LLC
Product
XD1035
Gehäuse
Metall
Weight (kg)
1,25
Color
Lila
Power supply type
Extern
Stromversorgung
12V, 3A (36 Watt)
Operating
-20° - +70° C
Abmessungen BxHxT mm
205 x 19,2 x 185,9 mm
Artikel Nr.
8998
