Multi-Screen Controller Set 2x2 DS-MSC22
DSMSC22
Manages audio and video signals to emulate a video wall when using third-party screens. This controller will control the digital signage content for each screen on a video wall system using up to 4 screens (available up to 25 screens). One controller is required per screen. If the user has only one HDMI or VGA source, then an appropriate Distribution Amplifier (Splitter) will be required to split the source signal to each of the Multi-Screen Controllers feeding the screens.
Legen Sie dieses produkte in den Beraterkorb und fordern Sie anschlieÃend eine kostenlose Beratung an!
Description
Technical Specification
Inputs:
1x HDMI [1x HDMI Uncompressed AV and Data]
1x Stereo mini-jack [1x Analogue Stereo(L/R)]
1x 15pin Dsub [1x RGBHV]
1x 9pin Dsub [1x RS-232 Data]
1x Stereo mini-jack [1x Infra Red Receiver]
Outputs:
1x HDMI [1x HDMI Uncompressed AV and Data]
2x RCA [1x Analogue Stereo (L/R)]
1x 9pin Dsub [1x RS-232 Data]
Resolutions supported:
Input: VGA bis SXGA; HDMI 720p & 1080p
Output: HDMI 720p & 1080p
Fully HDCP compliant
