Multiviewer DVI/HDMI/ Audio/ USB 4x1 Sequoia Dual
Sequoia Dual
Allows to input up to four HDMI video signals (optional Audio/ USB) and output them to one single display. The embedded software allows for seamless sizing and positioning of input windows.
Sequoia Module with 2 HDMI and 2 DVI-I Inputs Displaying any 2 of the 4 Input Sources- Two HDMI/DVI inputs support HDCP.- Two DVI-I inputs support DVI/YPbPr/VGA.- Integrated keyboard/mouse and audio switcher and USB hub.- Built-in headset plug with on screen volume and audio delay adjustment.- Cascade via USB A/B ports for control of multiple Sequoia Solo (including 4H and 2H2U) units with one sets of mouse/keyboard.
Legen Sie dieses produkte in den Beraterkorb und fordern Sie anschlieÃend eine kostenlose Beratung an!
Description
Technical Specification
Inputs Front panel:
1 x USB-B female
2 x USB-A feamle
1 x analog Audio
Inputs Back panel:
4 x HDMI feamle
4 x D-Sub male
Outputs Front panel:
1 x analog Audio
2 x Speaker (Stereo)
Otuputs Back panel:
1 x HDMI female
Control options:
LAN
Resolutions supported:
640x480 to 1920x1200 and 480i to 1080p
Formats supported:
Video: HDMI, HDCP 1.1 and DVI 1.0
Audio: 7.1 Surround sound
