Multiviewer Quadview 2+2
QuadView2x2
Displays up to 4 signals from 10 switched inputs. The user can choose up to any 4 signals for display from 2 RGB/DVI/HD and 4 composite/S-Video input, unlike lesser systems restricted to 2 of each type. In addition, inputs can be displayed at any size and position. Stretching and cropping capabilities are provided to best fit a 4:3 or 16:9 format. Contollable via ethernet or RS-232
Preis auf Anfrage
Legen Sie dieses produkte in den Beraterkorb und fordern Sie anschlieÃend eine kostenlose Beratung an!
Description
Technical Specification
Inputs:
2 x RGB/YPbPr/HD/DVI on DVI-I connectors
4 x C-Video (NTSC/PAL)
4 x S-Video
Outputs:
1x RGB/DVI on DVI-I connector
Resolutions supported:
Input:
RGB: up to 1920 x 1200
DVI: up to 1080p
Output:
up to 1920 x 1200
Producer
RGB Spectrum
Product
QuadView2x2
Gehäuse
Metall
Weight (kg)
5,45
Color
Schwarz
Power supply type
intern
Stromversorgung
100 - 240 V DC
Abmessungen BxHxT mm
438 x 45 x 297
Artikel Nr.
4458
