Pattern,- Audio Generator & Analyser HDMI2.0 / HDCP2.2 XA-3P
XA3P
Support 23 resolutions settings, 11 test patterns, and including System Analyzing, Cable Testing, Pattern Generator & EDID Management. The XA-3P also has scaling functionality enabling the user to down-scale a 4K UHD Source to 1080p in Analyzer Mode.
€ 650,00 Excl. VAT .
Legen Sie dieses produkte in den Beraterkorb und fordern Sie anschlieÃend eine kostenlose Beratung an!
Description
Technical Specification
Input:
1 x HDMI female
Outputs:
1 x HDMI femal
Control options:
Frontpanel
Resolutions supported:
up to 3840x2160@60Hz (YUV 4:4:4, 8-bit) and 4096x2160@60Hz (YUV 4:4:4, 8-bit)
Formats supported:
Video: HDMI2.0, HDCP1.4/2.2
Producer
CYP Europe
Product
XA3P
Gehäuse
Metall
Weight (kg)
0,30
Color
Silber/ Schwarz
Power supply type
Extern
Stromversorgung
USB/ Batterie
Abmessungen BxHxT mm
79 x 27 x 123
Artikel Nr.
7239
